In this QC Lab article, we will focus on active sources of EMI as they are often the highest concern and can generally be mitigated through some basic user knowledge and actions. Most electronic devices generate EMI at various frequencies, and at various strengths. When the EMI happens to be near the 457kHz frequency band, it can negatively affect the performance of transceivers. Keep in mind that most consumer electronics are not specifically designed for backcountry travel and have little regard for the sacred 457KHz frequency band.
Let’s start with some simple spectrum analyzer images to understand the concepts better. The signal from an avalanche transceiver in a relatively noise-free environment is shown in Figure 1 below. Some level of background noise is unavoidable in the real world. A truly noise-free environment can only be created in a laboratory setting. As you can see, the signal level is significantly higher than the noise level. The difference between these levels is known as the signal-to-noise (S/N) ratio. The S/N ratio is important as the transceiver’s processor utilizes this information to identify a true transceiver signal from everything else going on.
There has been an increasing amount of discussion around EMI and its negative effects on the performance of avalanche transceivers among the snow safety community. Although this is not a new topic, it is taking on a heightened level of awareness and importance as the number of winter backcountry users increases and people are carrying more personal electronic devices such as smart phones, smart watches, GPS devices, heated clothing, and electronic airbag packs.
The above images show the transmitting transceiver signal in a relatively noise free environment. If interference from another electronic device is introduced, the S/N ratio will decrease even further as spikes in noise will begin to drown out the desired transceiver signal making it indistinguishable. Can you tell the difference between the transceiver signal and noise spikes caused by active interference in Figure 3 below?
The QA crew drove out to the Bonneville Salt Flats west of Salt Lake City to find a wide-open barren space, away from as many possible sources of electromagnetic interference found in the city.
A transceiver in send mode was placed at the end of a 100m tape measure. It was then slowly approached with a searching transceiver until a steady signal, both distance and direction indicators, was indicated. The distance at this point was then recorded.
Various electronics often found in the backcountry were used in our test, including smart watches, GPS watches, smartphones, two-way radios, action cameras, satellite communication devices, electronic airbag packs, and even a snowmobile. The searching transceiver was held at 50cm from the torso using a static tether to help maintain the appropriate distance. Each item was then placed in a normal use position as noted below.
The goal was to determine how bad it might be to violate the 20/50 rule. To do so, many items were held closer than 50cm (i.e., heated gloves and smart watches). Each item was tested three times, and the average taken. We then calculated the reduction in range compared to a baseline with no other items present.
The QA crew drove out to the Bonneville Salt Flats west of Salt Lake City to find a wide-open barren space, away from as many possible sources of electromagnetic interference found in the city.
A transceiver in send mode was placed at the end of a 100m tape measure. It was then slowly approached with a searching transceiver until a steady signal, both distance and direction indicators, was indicated. The distance at this point was then recorded.
Various electronics often found in the backcountry were used in our test, including smart watches, GPS watches, smartphones, two-way radios, action cameras, satellite communication devices, electronic airbag packs, and even a snowmobile. The searching transceiver was held at 50cm from the torso using a static tether to help maintain the appropriate distance. Each item was then placed in a normal use position as noted below.
The goal was to determine how bad it might be to violate the 20/50 rule. To do so, many items were held closer than 50cm (i.e., heated gloves and smart watches). Each item was tested three times, and the average taken. We then calculated the reduction in range compared to a baseline with no other items present.
As you can see, there was a wide range of reductions in performance depending on the power of the devices, and how close they are to the searching transceiver.
Some Caveats:
1.) These items were tested one at a time, and it is likely that there would be a compounding effect from multiple concurrent devices.
2.) The testing was conducted using a single pair of transceivers and a random selection of electronic devices. They do not represent every device out there. Personal electronic devices will continue to get more powerful over the coming years.
Transceiver and electronic airbag pack manufacturers are continually refining their firmware to improve performance (much the same way the apps on your phone are continually being updated). Firmware updates can improve features, extend battery life, reduce harmful interference being generated, and improve the way interference signals are processed.
It is of utmost importance to keep your firmware updated for these products. But we know many people do not. Don’t be one of these people. Update your firmware now. It’s easy and can often be done using an app on your phone. Refer to the manufacturer’s website for information on performing firmware updates.
1. Be aware of EMI.
2. Is EMI the most important factor in your backcountry safety?
3. Some level of EMI is unavoidable but can be kept to a minimum by having awareness of what electronics are being used and where you place them. Good practice is to discuss this with your group at the trailhead before heading out.
4. Keep your firmware up to date on your transceiver and electronic avalanche pack.
5. Some modern transceivers can sense the presence of interference and will provide a visual indication on the screen that your search strip width should be reduced.
6. Like many mountain safety and risk decisions, it is your responsibility to understand your equipment and your group’s risk tolerance.
DISCLAIMER: We collaborate with other manufacturers of avalanche beacons and international snow safety organizations in publishing this general recommendation for transceiver interference. Avalanche Beacons from PIEPS and BD are equipped with PIEPS Auto-Antenna-Switch and PIEPS Signal Verification. The PIEPS PRO IPS avalanche beacon is equipped with the Inteference Protection System. Please consult the relevant product manual for more details and specific rules.
Transceiver and electronic airbag pack manufacturers are continually refining their firmware to improve performance (much the same way the apps on your phone are continually being updated). Firmware updates can improve features, extend battery life, reduce harmful interference being generated, and improve the way interference signals are processed.
It is of utmost importance to keep your firmware updated for these products. But we know many people do not. Don’t be one of these people. Update your firmware now. It’s easy and can often be done using an app on your phone. Refer to the manufacturer’s website for information on performing firmware updates.
As you can see, there was a wide range of reductions in performance depending on the power of the devices, and how close they are to the searching transceiver.
Some Caveats:
1.) These items were tested one at a time, and it is likely that there would be a compounding effect from multiple concurrent devices.
2.) The testing was conducted using a single pair of transceivers and a random selection of electronic devices. They do not represent every device out there. Personal electronic devices will continue to get more powerful over the coming years.
The takeaway here is that EMI is real, and it can have a significant impact on transceiver performance! And we can’t stress enough the importance of updating the firmware of your avalanche transceivers and electronic avalanche airbag packs.
